The Avantage of Steel Structure Workshop Buildings:

1. The construction speed is fast and the construction period is short.
2. The weight of material is light and the strength is high.
3. The performance on safety and seismic is good.
4. The flexible structure can meet the needs of multiple functions.
5. The steel structure materials can improve the use area of the warehouse building.
6. The steel structure has long service life, usually more than 50 years.
7. The materials are green, recyclable and environmental protection.

Specifications of Steel Structure Workshop:

* Design manufacture installation of steel structure workshop / warehouse / hangar / shed / poultry farm / livestock farm
* More information, Please visit our home page. Main Steel Frame: Column --- Q235, Q355 Welded H Section Steel
Beam --- Q235, Q355 Welded H Section Steel Secondary Frame
Purlin --- Q235 C and Z purlin
Knee brace --- Q23S Angle Steel
Tie Rod --- Q235 Circular Steel Pipe
Brace --- Q235 Round Bar
Vertical and Horizontal Support --- Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance system: Roof Panel --- EPS Sandwich Panel / Glass Fiber Sandwich Panel
Rock Wool Sandwich Panel / Pu Sandwich Panel / Stee Sheet Wall Panel --- Sandwich Panel / Corrugated Steel Sheet Accessories:
Window --- Aluminium Alloy Window / PVC Window /Sandwich Panel Window
Door --- Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
Rainspout --- PVC Live load on Roof in 120kg/Sqm (Color steel panel surrounded) Wind Resistance Grade 12 Grades Earthquake-resistance 8 Grades Structure Usage Up to 50 years Finishing Options Vast array of colors and textures available

Steel Structure Material:

1. Columns and beams
Material Q345 or Q235 Steel, Straight or Variable cross-section
2. Bracing
X-type or V-type or other types bracing made from round, angle pipes etc.
3. Purlin
C or Z type: Size from C120~C320, Z100~Z200
4. Wall and roof panels
Single Colorful Corrugated Steel Sheet
Sandwich panels with EPS, Rockwool, fiber glass, PU etc.
5. Bolts
High Strengthen Bolt, Normal Bolt, Post feet Bolt.
6. All Accessories
Skylight belts, Glass curtains, Ventilators, Down pipe, Rolling or Sliding door, PVC or aluminum alloy windows, Gutter etc.
7. Surface
Two lays of Anti-rust Paint

Design

1. Our company has an experienced design team, more than 8 senior engineers.
2. We use professional design software which can ensure the safety of products and control the amount of materials accurately and reduce the cost.
3. After project starting, we can provide a full set of design drawings (CAD drawings, 3D models) for customer to inspect and confirm.
